1. Initial Consultation
During this stage you arrive with an idea, rough sketch or a mock up part. Our engineers will work closely with you in product design and quality development to ensure your products do comply with your stringent standard, specification and quality.

2. Mold Fabrication
Various stages of processes will be carried out by our experience and skilful technicians comprising of mold makers, fitters, programmers, molding engineers and designers

3. Sampling and Production
Our services to you continue with the mold trial and production of samples including secondary processes like product assemblage, spray printing and packaging.

4. Shipment
The shipping company can be appointed by customer or just leave it to us. We will choose the reliable shipping agent according to shipping instruction from customer.

We assist the shipping agent with related documents. And we have personnel who will be responsible for following up the shipment and will feed back the latest status to our customer and ensure safe arrival of the products.

STEP 1

Request information from Customer for quotation

  1. Plastic Product Characteristic
  2. Injection Machine Specification
  3. Gate runner system preference
  4. Mold base preference
  5. Surface finish preference
  6. Type of material in tool components
  7. Delivery and payment methods
photos-Flow1

Request information from Customer for quotation

STEP 2

Discuss tooling characteristic

  1. Moldability product design
  2. Gate runner system solution
  3. Mold base size
photos-Flow2

Product development and mold design discussion

STEP 3

Use modern CAE/CAD/CAM tools to come out with:

  1. Layout 1,Layout 2, Final drawing for customer check & approval
  2. Assembly drawing
  3. Detail drawing
  4. Cam programming
  5. Plastic flow analysis
photos-Flow3

Research & Development

STEP 4

Each project development progress is check by project coordinator at least twice weekly using mold making progress chart and Microsoft project.

photos-Flow4

Project Scheduling

STEP 5

Mold base, steel raw materials and mold accessories are purchased according to customer requirement.
If customer doesn’t specify the above, quality if our first preference in purchase mold component in the tools.

STEP 6

The company uses high speed precision machines such as Fanuc, Okuma, Makino (Japanese machines) and HARFTFORD for mold making machinery.

photos-Flow6

Tool Fabrication

STEP 7

Experience tool makers perform tool fitting and assembling in sequence after prioritized tool components has been manufacture.

photos-Flow7

Tool Assembly

STEP 8

At least two mold trials will be conducted to ensure plastic product meet customer requirement.

photos-Flow8

Tool Testing

STEP 9

Tool(s) is(are) pack into heat treated wooden box with qualify and certified supplier to minimize the moisture content in the box to prevent rust.

photos-Flow9

Packing

STEP 10

Transportation is done base on customer requirement.

photos-Flow10

Oversea or Local Delivery (air or sea freight)
